Fuel Cell Mount for JAZ Pro Sport 22 gallon

Artec Industries

$ 148.50 $ 164.99

Fuel Cell Mount for JAZ Pro Sport 22 gallon
Fuel Cell Mount for JAZ Pro Sport 22 gallon Fuel Cell Mount for JAZ Pro Sport 22 gallon Fuel Cell Mount for JAZ Pro Sport 22 gallon

Artec Industries

$ 148.50 $ 164.99

has been successfully added to your cart. Feel free to continue shopping or check out.

The JAZ Pro Sport 22 Gallon Fuel Cell Bracket is designed to add style, simplicity, and strength in securing your fuel cell. Don't compromise your safety; secure your JAZ fuel cell with this Artec Fuel Cell Bracket. Get a mount that's more stylish than two straps of steel.



Features two CNC cut, bent, and dimple died tops cut from 16 gauge cold roll steel, two 10 gauge side brackets, and two 10 gauge bases for uncompromised strength. Bases are shaped like c's to allow notching for tube chassis. For flat surface mounting such as in a truck bed, simply don't use the bases. 6 pieces total. 1/4" hardware included.



Please choose the appropriate 22 gallon JAZ Pro Sport fuel cell:

 MODEL 622 which measures 25 L x 16.75 W x 13.625 H.

 MODEL 122 which measures 34.5 L x 18.375 W x 10.5 H.

 MODEL 222 which measures 25.75 L x 17.375 W x 14.5 H.



These mounts fit Pro Sport and Pro Sport II fuel cells that have a prefix of 270, 272, 273, 274, 280, 281, 282, or 283 (ie: 270-622-06). Works for foam or non-foam variations of this fuel cell. Bare steel finish, requires paint, powdercoat, or plating to not rust. Bolt holes on top mounts line up to bolt holes on flange of fuel cell. These tops are wide enough to allow additional bolt holes to be drilled across the flange for extra security which is recommended for high speed racing.



NOTE: This mount will require additional drilling on the fuel cell flange for bolt holes. Artec is not responsible for improper hole drilling on fuel cell.
